HBM T10FS User Manual

Specifications
T10FS A0785-150 HBM: public 93
Nominal (rated) torque M
nom
10 k5 k3 k2 k1 k500200100N⋅m
Maximum control range
3
Frequency output
Voltage output
kHz
V
4 ... 16
-10.5 ... +10.5 (typ. ±11)
Power supply (version KF1)
Excitation voltage
(square wave)
V 54±5% (peak‐to‐peak)
Calibration signal
triggering
V 80±5 %
Frequency kHz approx. 14
Max. current consumption A 1 (peak‐to‐peak)
Preamplifier excitation
voltage
V 0/0/+15
Preamplifier, max. current
consumption
mA 0/0/+25
Power supply (version
SF1/SU2)
Nominal (rated) supply
voltage (separated
extra‐low voltage (SELV))
V
DC
18 ... 30; asymmetrical
Current consumption in
measuring mode
A < 0.9
Current consumption in
startup mode
A < 2
Nominal (rated) power
consumption
W < 12
Linearity deviation including
hysteresis, relative to the
nominal (rated) sensitivity
Frequency output % <±0.05 (optional <±0.03)
Voltage output % <±0.07 (optional <±0.05)
