Dimensions
T10FS A0785-150 HBM: public 83
11.3 Stator dimensions
2)
Clamp fixture not
mounted as standard!
Standard
screw fitting
Side view Y
Side view X
100
210
+2
150
+2
H3
max.
H2
ca. 100
3)
25
h
77
52.5
29.5
∅20
83.5
approx. 3
52.5
106
Connector 1
Plug 2
2)
Plug 3
4)
b
l
Rot
l
Ref
∅ D
∅ d
43
1)
max. ∅ 4
50
22
1)
For option 5, code A only; otherwise 18mm
2)
For the speed measuring system option only
3)
Space for connection cable with connector
4)
Does not apply to version KF1
2)
Accuracy of the cast base sizes as per DIN 1688-GTA 14/5
Top view
H1
10
190
9
