Dimensions
84 A0785-150 HBM: public T10FS
Measuring
range
Dimensions (in mm; 1 mm = 0.03937 inches)
b ∅d ∅D H1 H2 H3 h l
Rot
l
Ref
100 N⋅m
200 N⋅m
17.5 125 155 235 239 253 157.5 42.5 42.5
500 N⋅m
17.5 145 175 255 259 273 167.5 42 42.5
1 kN⋅m
2 kN⋅m
20.5 181 211 291 295 309 185.5 42.5 43
3 kN⋅m
5 kN⋅m 22.5 215 245 324 329 343 202.5 57 57
10 kN⋅m 28.5 263 293 373 377 391 226.5 58 58
