HBM T10FS User Manual

Settings
58 A0785-150 HBM: public T10FS
8 Settings
Notice
You will find a table containing all the relevant switch
positions on the back of the stator cover. Changes to the
factory settings should be noted or entered here using a
waterproof felt‐tip pen.
Impulse /
Umdrehung
Pulses / revolution
720360 180 90 60 30 15
Einstellungen / Settings OPTION 5
M
nom
100 N⋅m
to
3 kN⋅m
M
nom
5 kN⋅m
to
10 kN⋅m
Hysterese
Hysteresis
ein/on aus/off
CH1
CH2
Frequenz
Ausgangsspannung
Frequency output
voltage
ON
DIP
1 2 3 4 5 6
Factory settings
Customized settings
CH1
CH2
2xf
Fig. 8.1 Sticker with switch positions; optical speed
measuring system
