HBM T10FS User Manual

Electrical connection
T10FS A0785-150 HBM: public 45
6.1.1 FCC and IC compliant installation for US and
Canada installation only
Use of EMI suppressor
To suppress high frequencies a EMI suppressor on the
power cable has to be used. Use at least 3 loops of the
cable.
Fastening must be done in an area not subject to
mechanical loads (i.e. no unwanted vibrations, etc.) using
cable ties fit for the specific application.
EMI suppressor
Cable ties
Mounting fixture
3 Loops
Fig. 6.1 Installation example EMI suppressor
Information
Consider longer cable of approximately 40 cm due to the
installation of the EMI suppressor.
