HBM T10FS User Manual

Settings
68 A0785-150 HBM: public T10FS
Notice
Please make sure that when you change the pulse count,
you also change the pulse duration!
We recommend giving preference to the output pulse
counts selected by switches F1...F3. By using pulse
division (switches S1...S4), it is possible to increase the
pulse tolerance stated in the specifications.
Other quantities, such as the eccentricity and the relative
movement between the rotor and the stator can affect
the pulse tolerance.
8.5.2 Optical speed measuring system
Notice
The factory setting is 360 pulses/revolution. Please make
sure that when you change the pulse count, you also
change the pulse duration!
pulseduration +
1
2 @ pulsecount @ speed
The number of pulses per rotor revolution can be
adjusted by means of DIP switches S1 ... S4.

HBM T10FS Specifications

General

Brand	HBM
Model	T10FS
Category	Measuring Instruments
Language	English
