Mechanical installation
T10FS A0785-150 HBM: public 31
3. Clamp a suitable support element (we recommend a
threaded rod
36 mm) between the upper and lower parts of the
clamp fixture and tighten the clamping screws.
Support supplied by the
customer, e.g. threaded
rod
Clamp fixture
Fan‐type lock washers
Antenna segments
Fig. 5.6 Installing the clamp fixture
Notice
Use, e.g. plastic as the material. Do not use metallic
material as this can affect the function of the antenna
(signal transmission).
