Heal Force Smart-Mini - Installation of Pretreatment Cartridge

11
A
B
C
D E
F
A D
Instructions to the main component
A
Pretreatment
cartridge
B
RO cartridge
C
UV light
D
Ultra-Purifica
tion cartridge
E
Ultra-Purificatio
n cartridge
F
Micro-filter
4.3.3 Installation of pretreatment cartridge
A
B
C
D
Confirm the Smart-Mini system is power off.
Pretreatment cartridge is installed in the right chamber of smart-Mini system.
Get the pretreatment cartridge from the box (make sure number is correct for the
CR-SP101M), open the vacuum bag, remove protection cover for the inlet and outlet of
pretreatment cartridge. Make sure there is a black “O” ring in the inlet and outlet, which is in
the bottom of the hole.
Use pure water to make the black "O" rings wet. Do not use lubricants for lubrication,
such as glycerol or Vaseline or other lubricant.
