Chapter 5 Parameter setting and operation
5.1 Control panel area
A
B
A: dashed box for the LCD display area.
B: dashed box for the function keypad board.
5.2 LCD display area
A: system model and the current temperature display .
B: current status
C: product water quality and Volume dispense status.
D: date and feed water conductivity.
E: graphic for display status.
5.3 symbols and graphics for LCD display
symbols
FEED
Feed water
conductivity
RO
Pure water
conductivity
UV
UV light
DS
RO deionization
rate
PF
Pretreatment
cartridge
MF
Micro-filter
Vol.
Disp.
Fixed Volume
Dispensing
UP
Products
resistivity
