4
risk of RO membranes seepage when the main unit is in standby mode.
Volume dispense function (0.1-25L adjustable) or water producing amount according
to your needs
PIN-coded access to software set points prevent unauthorized changes to operation or
system settings.
RS232 port allows for data collection and permanent record of water quality and
system parameters--essential for compliance with good laboratory practice guidelines.
With remote monitor software (option),you can remote the water system on the
computer.
2.3 Specifications for the system
Smart-Mini
Feed water
requirement
Conductivity μS/cm@25℃
<400
Pressure MPa
0.1~0.4
Temperature ℃
5~40
Pure water
Specification
Ion rejection rate %@25℃
≥95
Bacteria remove %
>99
Products resistivity MΩ.cm
>18
Make rate* L/H@25℃
25-30
Dispensing rate L/H
25-30
TOC** ppb
1-10
Particles***(0.22μm) /ml
<1
Bacteria*** cfu/ml
1
Power Consumption W
85
Weight kg
30
Main System
Dime. W*D*H
525*314*571
Note:
* The making rate will be changed with temperature variation. (3% per 1℃)
** The feed water TOC is less than 1000ppb.
*** with 0.22um final filter cartridge
