Fig.11 Fig.12
Charging system blocking devices
Authentication via RFID card
RFIDauthentication(e.g.thesuppliedRFIDcards)can
protect the charging system against unautorised use.
YoucanenableRFIDauthenticationviatheapporthe
Webinterface:
1. Launch the teach-in mode via the app or the Web
interface(StatusLEDonthechargingsystemlights
uppurple).
2. HoldtheRFIDcardinfrontoftheRFIDsymbolon
thechargingsystemwithin60seconds.
3. The card has been accepted as soon as the Status
LEDlightsupgreenandasinglesignaltonesounds.
HoldtheRFIDcardinfrontofthechargingsys-
tem’ssensoreldtoenablethechargingprocess
(Fig.11 - no.3).
External blocking device
Anexternalblockingdevice(e.g.key-operatedswitch)
can protect the charging system against unauthorised
use. When the charging process is requested, the system
checkswhetheranexternalblockisactive.Usethedata
interfaceENasshowninFig.6 - no.2.
Charging a vehicle (Fig.12)
1. Pull the charging coupler out of the coupler holder.
2. Fullyunwindthechargingcablefromthecharging
system.
3. Optional:Enablethechargingsystemusingyour
RFIDcardorviatheexternalblockingdevice.
4. Plug the charging coupler into your vehicle.
End of charging
Unplug the charging cable from the vehicle when the
charging process is complete. Wind the charging cable
onto the charging system and insert the charging
coupler into the coupler holder.
Tripping hazard from unwound charging
cable. Risk of cable breakage! Do not wind
the cable too tightly.
Interrupting charging
There are three options for stopping the charging
process:
• End the charging process using the vehicle’s control
elements. Refer to the vehicle’s driver’s manual for
this purpose.
• Disconnectthechargingsystemfromthepower
supply by switching off the building’s circuit breakers.
• Ifthechargingsystemisttedwithanexternal
blocking device, you can use it to stop the charging
process.
Cleaning the charging system
Neveruseaggressivecleaningagents(e.g.petroleum
ether, acetone, ethanol or methylated spirit-based glass
cleaner)whencleaningthechargingsystemandpar-
ticularly the plastic window. These agents could attack
or damage the surface. Use mild detergent solutions
(washing-upliquid,neutralcleaner)andasoft,damp-
ened cloth for cleaning.
1
2
3
4
5
6
7
3 4 5 6 71 2
Charging
thevehicle
