HEIDENHAIN MANUALplus 4110 User Components 2.2
Data input keypad
Numbers (0 to 9) For value entry
Decimal point key For entering the decimal point
Minus key For entering the algebraic sign
Enter key Confirms the entered value
Store key Concludes data input and stores values
Arrow keys Moves the cursor in the indicated
direction by one position (character, field,
line, etc.)
Page forward/
Page back
 Shows the information on the
previous or next screen page
 Switches between two input windows
Info key Calls the error information or PLC status
display
