HEIDENHAIN MANUALplus 4110 Executing Programs 11.7
Tool compensation
Repeat the finishing cycle with the corrected tool
 Add the compensation
value:
Press the Save soft key
(Compensation is activated.
It is shown in the T6 dx field
and in the DX field of the
dialog box.)
 Exit the “Tool correct”
function:
Press the Back soft key
 Return to program run:
Press the Back soft key
 Position the cursor on the
finishing cycle again:
Press the arrow key
 Activate the “Continuous
run” mode:
Press the Continuous run
soft key
(Cycles are run
continuously, without
interruption, up to the next
tool change.)
 Repeat the finishing cycle, then run the other cycles
