HEIDENHAIN MANUALplus 4110 Tool Management 4.7
Create tool T6 by copying
Assume tool data and specify the position in the tool manager
The setting dimensions are assumed at first, and will be determined exactly later.
Finishing tool T6  Cutting radius: 0.4 mm
 Tool angle: 93°
 Tip angle: 55°
 Load the tool data T2 into
the intermediate memory:
Press the Copy soft key
 Place the cursor on position
T6:
Press the arrow key
repeatedly
 Insert the tool data from the
intermediate memory to
position T6:
Press the Insert soft key
