HER CHEE ADLY RT-50 - Chapter 3: Engine Removal Parts List

4-2
Chapter 4 Engine Removal
Operation / Parts Name Q’ty Remarks
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Disassembly
ACG wire /wire of start motor
Starter wire of carburetor
Oil tube
Fuel tube
Vacuum pressure tube
Cap of spark plug
Hex washer face bolt of rear
cushion
Oil pump control cable
Cable of rear brake
Throttle cable
Hex washer face bolt of engine
Bolt
Engine
Nut
Engine bracket bolt
Engine bracket
2
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
WARNNING:
• The oil over-flow when remove the oil
tube, so use clip or plug stop the seal.
WARNNING:
• Don’t damage rear fender when remove
the engine.
• Actually for brace the frame, avoid body
turn inside out.
Assembly
16→1
WARNNING:
Carry out following adjusting after
installation.
–Cable of throttle valve
–Oil pump control cable
–Rear break cable
