4-1
Chapter 3 Engine Removal
Attention of Operation
• Following operation needs remove the engine from frame body.
–Disassembly crank shaft case
–Remove crank shaft
–Exchange bearing of final transmission mechanisms.
Disassembly of Engine
• Disassembly of external cap of body.
• Disassembly of luggage case.
• Disassembly of throttle valve.
• Adjustment the throttle cable.
• Adjustment the rear break cable.
• Adjustment the oil pump control cable.
