Chapter 6 Transmission
Disassembly Driver Pulley Sliding
Ass’y
Remove driver pulley sliding ass’y from
driver shaft.
Detach the bushing, cam plate and
weight roller from driver pulley sliding
ass’y.
Inspection
Check the bushing sliding smoothly or
not.
Measure the width of weight roller.
Standard: 15.0 mm
Wear Limited: 14.5 mm
Replace all six roller at same time.
To Next Page
