HER CHEE ADLY RT-50 - Chapter 11: Starting Motor Components

Chapter 11 Electrical Device
Starting motor
Operation / Parts name Q’ty Remarks
1
2
3
4
5
6
7
Separation
Bolt set
Casing
Armature rotor
Carbon brash
Oil ring
Oil ring
Front fixed seat
2
1
1
2
1
1
1
Assembly
7→1 Install in reverse order of disassembly.
