HER CHEE ADLY RT-50 - Chapter 10: Rear Wheel Disassembly

Chapter 10 Rear Wheel / Suspension / Brake
Disassembly of Rear Wheel
Operation / Parts name Q’ty Remarks
1
2
3
Disassembly
Muffler
Hex washer face bolt
Hex socket bolt
Muffler
2
2
1
4
5
Rear wheel
Nut
Rear wheel
1
1
Assembly
5→1
–Operation with sequence in reverse
procedure.
4
5
