Carburetor Ass’y
Air adjust screw set
Throttle screw set
Pilot jet
Needle nozzle
Main nozzle
1
1
1
1
1
WARNNING:
Must confirm rotation location before
disassembling, not locking too much
avoid to hurt seat face.
11
Assembly
15→1
Install carburetor in reverse order
of disassembly.
Air adjust screw set
WARNNING:
Use high pressure air clean each way of
carburetor.
WARNNING:
Must adjust air screw when changing air
screw and carburetor ass’y.
To Next Page
