HER CHEE ADLY RT-50 - Chapter 9: Steering Handle Disassembly

Chapter 9 Front Wheel / Front Suspension / Front Brake
Disassembly of Steering Handle
Disassembly of throttle handle
Dismount rear brake cable
Operation / Parts name Q’ty Remarks
1
2
3
4
Disassembly
Rear brake lever
Nut
Left lever set bolt
Rear brake lever
Rear brake cable
1
1
1
1
5
6
7
Bracket of rear brake lever
Hex socket bolt
Fixed belt of steering handle
Bracket of rear brake lever
1
1
1
8
9
10
11
12
Steering Handle
Hex flange nut with serration
Washer
Hex washer face bolt
Steering handle
Handle grip
1
1
1
1
1
11
7
4
Assembly
12→1
Steering handle
Bracket of rear brake lever
Rear brake cable
1
1
1
Operation with sequence in reverse
procedure.
WARNNING:
Install steering handle with handle
convex at ditch of steering stem.
The convex of brake lever bracket
should be fit into handle bar.
