HERO MAESTRO EDGE - Left Side View

9
7
12
*Optional in LX Model
8
2
3
4
5
6
1
(1) Side stand switch (optional)
(3) Main stand
(4) Pillion step
(2) Side stand (optional)
(9) Rear grip
(10) Boot lamp* (inside)
(13) Headlamp
(11) Seat
(12) Rear luggage hook*
13
LEFT SIDE VIEW
11
(5) Kick starter pedal
(7) Rear turn signal lamp
(8) Tail/stop lamp
(6) Women pillion step (optional)
11
SCOOTER VIEWS
Accessories and features shown may not be part of standard fitment.
