HERO MAESTRO EDGE - Operations; Pre-Ride Inspection

35
(1) Screws
1
î Remove the two screws (2) near the front
fender.
(2) Screws
2
Release the front center cover lugs (3) from
the mounting clips. Remove the front center
cover by pulling it axially downwards towards
front.
Installation can be done in the reverse order of
removal.
Installation
3
(3) Lugs
12
î Pull the body cover (12) slightly backwards
and carefully remove the tabs (13) from
the slots.
î Remove the complete body cover.
Installation can be done in the reverse order of
removal.
Installation
Removal
Front center cover
î Remove the two screws (1) on the inner
cover side.
13
