34
î Remove the body cover bolts (8).
(8) Body cover bolts
î Disconnect the fuel tank lid lock cable (9).
(9) Fuel tank lid lock cable
9
(10) Tail/stop lamp connector
î Disconnect the tail/stop lamp connector
(10).
10
11
î Disconnect the drain tube from the joint
(11).
(11) Drain tube
8
î Remove the fuel filler cap (page 18).
To Next Page
