14
If only one vertical bar is displayed and blinks,
this indicates that the fuel quantity is low and
the fuel tank should be refilled as soon as
possible.
LCD PANEL
The odometer (1) shows accumulated distance
traveled.
Tripmeter displays upto 999.9 km If the
tripmeter exceeds "999.9" km it will return to
"0.0" km automatically.
ODOMETER/TRIPMETER
The tripmeter (2) shows distance traveled since
trip meter was reset last time.
When tripmeter is selected long press the reset
button (3) will reset tripmeter to zero.
The odometer displays from "0 to 999999" km
If all the vertical bars (2) are displayed it
means fuel quantity in the fuel tank is 5.5
litres.
(1) Fuel gauge (2) Vertical bars
The fuel gauge (1) is of a Liquid Crystal
Display (LCD) type.
FUEL GAUGE
The approximate amount of fuel quantity
available in the fuel tank is indicated by the
number of vertical bars in the display. Each
segment display approx. 1.0 litre of fuel.
The service reminder shall start blinking when
the vehicle covers kilometers as specified in
the maintenance schedule. The service
reminder will keep on blinking throughout the
kilometer interval for a particular service and
will stay “ON” thereafter.
The service reminder can be reset at an
Authorised Hero MotoCorp workshop.
SERVICE REMINDER
The service reminder (1) is to indicate to an
user to bring the vehicle to an Authorised
Hero MotoCorp workshop for service.
2
1
(1) Odometer
(2) Tripmeter
(3) Reset button
3 1
2
