36
Installation
Installation is in the reverse order of removal.
(3) Screws(2) Bolts
2
3
4
(4) Screws
î Remove the screws (4) from the floor side
covers.
î Remove the left and right front covers and
disconnect the front turn signal lamp
connectors.
î Remove the four bolts (2) from the front
cover.
î Remove the top and bottom screws (3).
Front cover
Removal
î Remove the four screws (1) on the inner
cover side and remove two screws from
front inner box. Remove front inner box.
î Remove the front center cover (page 35).
(1) Screws
1
To Next Page
