The Headlamp operates only when the
engine is running.
2. Starter switch ( )
The starter switch (2) is next to the throttle
grip.
When the starter switch is pressed, the starter
motor cranks the engine. See (page 39) for
the starting procedure.
(1) Headlamp switch (2) Starter switch
IMPORTANT: To switch “OFF” the turn
signal after completing the turn, gently push
inside as directed on the switch.
1. Dimmer switch/Passing switch
Press the switch upwards for High Beam
“ ” downwards for Low Beam “ ” .
Press the switch to “PASS” position to
operate the passing lamp.
2. Turn signal switch ( )
3. Horn switch ( )
Press the switch to operate the horn.
Shift the turn signal switch sideways for
Right/Left indications and leave it to come
back to its normal position on its own.
(1) Dimmer switch/Passing switch
(2) Turn signal switch
(3) Horn switch
LEFT HANDLEBAR CONTROLS
The switch has three positions.
RIGHT HANDLEBAR CONTROLS
1. Headlamp switch
marked by White dot.and
Position
Action
Headlamp “ON”
î Fuel gauge lamp
î Speedometer lamp
“Following is “ON”
î Position lamp
î Tail/Stop lamp
“OFF”
1
2
1
2
24
3
