HERO MAESTRO EDGE - Scooter Views; Top View

(5) Throttle grip
(7) Parking lever
(1) Turn signal indicator
(3) Horn switch
(4) Turn signal switch
(2) Choke knob
(6) Integrated brake lever
(9) Dimmer switch/Passing switch
(10) Side stand indicator
(11) Hi beam indicator
(8) Rear view mirror
Accessories and features shown may not be part of standard fitment.
TOP VIEW
17
6
10
13
18
9
(16) Tripmeter
(21) Odometer
(19) Starter switch
(12) Speedometer
(13) Fuel gauge
(14) Service reminder
(15) Immobilizer/Malfunction indicator
(18) Front brake lever
(20) Ignition switch with steering lock
(17) Headlamp switch
1
5
7
8
10
11
14
16
SCOOTER VIEWS
2
3
4
12
15
19
20
21
