HERO MAESTRO EDGE - Pillion Footrest; Body Parts Removal; Center Compartment

31
Ensure that adequate care should be taken while
cleaning the side stand switch.
CAUTION
î If the side stand indicator (1) does not
operate as described in above steps, please
visit your Authorised Hero MotoCorp
workshop.
î Check the side stand for proper function and
the spring (3) for damage or loss of tension and
the side stand assembly for free movement.
î Check whether the side stand indicator (1)
glows when the side stand is down.
î When the side stand is up, the side stand
indicator (1) should not glow.
(2) Side stand switch (3) Side stand spring
2
3
(2) Right footrest
Move the right and left footrest in the direction
shown by arrows to open. Folding can be done
by moving footrest in the reverse direction.
PILLION FOOTREST
(1) Left footrest
2
1
î Remove the bolts (1) from the center
compartment.
BODY PARTS REMOVAL
î Open the seat (page 25).
Removal
Center compartment
