43
3
CLOSE
î When slowing down the scooter,
coordination of the throttle (3), front (4)
and integrated brake (5) is most important.
(3) Throttle
Do not accelerate with the brakes applied,
this may lead to premature wear of brakes
and transmission parts.
î To decelerate, close the throttle.
3
OPENCLOSE
Excessive brake application may cause the
wheels to lock, reducing control over the
scooter.
Since the scooter is equipped with an
integrated braking, by pressing the brake
lever provided on the left side of the
handlebar would ensure both front and rear
brakes applied simultaneously.
SEAT
OPEN
LOCK
PUSH
PUSH
FULL
OPEN
IG
PASS
20
0
40
00
20
F
E
TRIP
ODO
km
km
k
m/
h
(4) Front brake (5) Integrated brake
5 4
Do not "BLIP" the throttle (open and close
rapidly) as the scooter will move forward
suddenly, causing possible loss of control
and loss of fuel economy.
î To accelerate, open the throttle (3)
gradually, the scooter will move forward.
