HERO XPULSE 200 PROGRAMMED FI - LEFT SIDE VIEW; Left Side View Components

(6) Main stand (optional)
(3) Starter motor
(5) Rider footrest
(4) Gear shift pedal
(1) Side reflex reflector
(2) Front hugger fender
(7) Side stand
(11) Rear grip
(8) Pillion foot rest
(9) Saree guard
(10) Seat lock
(12) Seat
(14) Battery compartment (inside)
(16) Front fender
(13) Left side cover
(15) Side stand switch
