Device overview
max. speed (RPM) 15000
max. acceleration (RCF) 24400
max. kinetic energy 24000 Nm
Obligation to perform
checks
(DGUV Rules 100-500)
(valid only in Germany)
yes
Ambient conditions (EN / IEC 61010-1):
Installation site indoors only
Altitude up to 2000 m above sea level
Ambient temperature 5°C to 35 °C
Humidity maximum relative humidity 80%for temperatures up to 31°C,
decreasing linearly to 50%relative humidity at 40°C.
IP ratings IP 20
Overvoltage category
(IEC 60364-4-443)
II
Pollution level 2
Device protection class I
not suitable for use in potentially explosive atmospheres.
EMC:
Emitted EM interference,
EM interference immunity
EN/IEC61326-1
Class B
FCC Class B
Noise level
(rotor-dependent)
£58dB(A) £64dB(A) £58dB(A)
Dimensions:
Width 713 mm
Depth 654 mm
Altitude 423 mm
Weight approx.107.5kg
109kg (4706-50)
approx.117kg
