Hettich 4701 - ‎3.6 Original spare parts‎; ‎3.7 Scope of supply‎

AB4701en_SARev.: 05 / 11.2023
18 / 62
Device overview
Fig. 15: [RPM] button
Fig. 16: [START] button
Fig. 17: [T/°C] button
Fig. 18: [TIME] button
Fig. 19: [STOP/OPEN] button
■ Speed, parameter RPM.
Adjustable from 50RPM to the maximum rotor speed (N
max
), in incre-
ments of 10.
■ Switch to RPM value.
■ Start centrifugation runs.
■
Save entries and changes.
■ Go to ‘Machine Menu’ and open the submenus.
■ Temperature (for centrifuges with cooling)
Adjustable in degrees Celsius (°C) or degrees Fahrenheit (°F).
Parameter T/°C=degrees Celsius (°C). Adjustable from -20°C to +40°C,
in 1°C increments.
Parameter T/°F=degrees Fahrenheit (°F). Adjustable from -4°F to
+104°F, in 1°F increments.
The lowest achievable temperature is rotor dependent.
■
Temperature (for centrifuges with heating)
Enable or disable heating, parameter Heater.
■ Scroll backward in the menus (the button is blank for centrifuges without
cooling).
■
Runtime, parameter t/hms.
h: Hours. from 1h to 99h, in 1hour increments.
m: Minutes. from 1min to 59min, in 1minute increments.
s: Seconds. from 1s to 59s, in 1second increments.
■
Continuous operation "¥"
■
Set the start of the runtime count.
■
End the centrifugation run.
The rotor coasts to a stop with the preselected ramp-down parameter.
■
Pressing the button twice triggers the quick stop function.
■
Unlock the lid.
■
Exit parameter input and the menus.
3.6
Original spare parts
Only use original spare parts from the manufacturer and approved accesso-
ries.
3.7
Scope of supply
The following accessories are supplied with the centrifuge:
■ 1 grease for the trunnions
■
1 Hex key (5 mmx170)
■
1 right-angled hex key (2.5 mm)
■
1 6-lobe (Torx) pin key wrench, short (T20 SG)
■
1 power cable
■
3 Cheese head screws M6x110
■
3 Spacer rollers
