AB4701en_SARev.: 05 / 11.2023
7.7 Program links
7.7.1 Linking programs or changing a program link
25program links can be stored (program locations AtoZ,
program location J does not exist).
A program link can consist of a maximum of 20 programs.
In a program link, the speed from one program to the next
is always adjusted with the ramp-up parameter of the next
program.
No centrifugation parameters can be changed in a program
link. Changing the parameters is only possible in the indi-
vidual programs.
No continuous operation programs or programs with ramp-
up and ramp-down times may be linked.
The [TIME] button can be used to retrieve the total runtime
of the program link and the runtime of the currently running
program during the centrifugation run.
Program links are enabled.
1.
Press the
[PROG]
button repeatedly until
‘EDIT A…Z ’
is displayed.
2. Use the
[Rotary knob]
to set the desired program location where the
program link is to be saved.
3. Press the
[START]
button.
🡆 The program location of the program link and the rst program of
the program link are displayed.
4. Use the
[Rotary knob]
to set the rst program of the program link.
5. Press the
[PROG]
button.
🡆 The next program in the program link is displayed.
6. Use the
[Rotary knob]
to set the next program of the program link.
7. Press the
[PROG]
button.
🡆 The next program in the program link is displayed.
8. Repeat steps 6 and 7 until all programs are set.
9. Use
[Rotary knob]
to set
‘END’
. For this, turn the rotary knob anti-
clockwise.
No
‘END’
can be set after the 20th program in the case of program
links consisting of 20 programs.
10. Press the
[START]
button.
🡆
‘STO B’
is displayed.
11. Press the
[START]
button to save the program link.
🡆
‘Multi program store...’
is displayed briey.
7.7.2 Opening a program link
1. Press the
[PROG]
button repeatedly until
‘RCL A…Z’
is displayed.
2. Use the
[Rotary knob]
to set the desired program location.
