Callout Name Description
5. Model
Displays the model number of the product. The same is
configured with the factory settings of the device and
reflects in this section on system boot up
6. Product Name
Displays the name of the product
7. Current Mode
Displays the current acting mode of the AP (Thick mode
or Thin mode)
8. Current Partition
Displays the current partition in use (Primary or
Secondary)
9. Local Time
Displays the date and time details according to the time
zone allocated in the “System Configuration” screen
10. System uptime
Displays the time duration since the respective AP board
is up and successfully running without any shutdown
11. CPU Load Average 5 min Displays the average load on the device
12. On Board Temperature Displays the board temperature
13. Longitude Displays the longitude coordinates of the Access Point
14. Latitude Displays the latitude coordinates of the Access Point
15. Memory
Displays the used and free CPU memory of the Access
Point
16. IPv4 Address Displays the allocated IPv4 address
17. IPv6 Address Displays the allocated IPv6 address
