Callout Name Description

6. Time Zone

Select the respective “Timezone” from the dropdown list.

It represents the region of the globe that observes a

uniform standard time for legal, commercial, and social

purposes. The date and time of the respective timezone

will be reflected in the system summary of status

overview screen.

7. Time sync/ NTP

Click on the check box and enable or disable the NTP

client

8. NTP Server candidates Click on the + icon and add multiple servers

Click on “Save & Apply” to save the system admin password configuration or click “Reset” to configure the
