Wi-Fi 6 2x2:2 User Manual Rev: A0-00

CONFIDENTIAL

Callout Name Description

7. IPv6 address

Enter the “IPv6 address”. Unique address of the

Host/Device e.g.2001:11::100

8. IPv6 prefix length

Specify the prefix length for IPv6 address. Specifies the

number of bits that belong to network part. The prefix-

length specifies a range of devices

e.g. IPv6 prefix length = 64 means range of IP addresses

between 2001:0DB8:ABCD:0012:0000:0000:0000:0000

and 2001:0DB8:ABCD:0012:FFFF:FFFF:FFFF:FFFF.

9. IPv6 gateway

Enter the “IPv6 gateway”. Gateway address is given to

reach other network device e.g.2001:11::1

Click “Save & Apply” to save the general network setup configuration or click “Reset” to configure the same

again.
