User Manual of PanoVu Series Network Camera
Steps:
1. Enter the audio exception detection interface:
Configuration > Event > Smart Event > Audio Exception Detection
Figure 6-13 Audio Exception Detection
2. Check the Audio Loss Detection checkbox to enable the audio input exception detection.
3. Check the Sudden Increase of Sound Intensity Detection checkbox to enable the sudden rise
detection.
Sensitivity: Range [1-100], the smaller the value the more severe the sound change will
trigger the detection.
Sound Intensity Threshold: Range [1-100], it can filter the sound in the environment, the
louder the environment sound, the higher the value should be. You can adjust it according
to the actual environment.
4. Check the Sudden Decrease of Sound Intensity Detection checkbox to enable the sudden
drop detection.
Sensitivity: Range [1-100], the smaller the value the more severe the sound change will
trigger the detection.
5. Click tab to enter the arming schedule setting interface. The time schedule
configuration is the same as the settings of the arming schedule for motion detection. Refer to
Step 5 in Section 6.1.1 Configuring Motion Detection.
6. Click tab to select the linkage method taken for the video loss alarm. Send
Email, Notify Surveillance Center, Trigger Alarm Output, and Trigger Recording are selectable.
Refer to Step 3 in Section 6.1.1 Configuring Motion Detection.
7. Click to save the settings.
