Network Video Recorder User Manual
75
Chapter 7 Event and Alarm
7.1 Set Motion Detection Alarm
Enter a short description of your task here (optional).
Steps
1. Go to Menu → Camera → Motion and choose a camera you want to set up motion detection.
Figure 7-1 Motion Detection Setup Interface
2. Set up detection area and sensitivity.Tick Enable Motion Detection, use the mouse to draw
detection area(s) and drag the sensitivity bar to set sensitivity.Click and set alarm response
actions.
3. Click Trigger Channel and select one or more channels which will start to record/capture or
become full-screen monitoring when motion alarm is triggered, and click Apply to save the
settings.
Figure 7-2 Set Trigger Camera of Motion Detection
