Chapter 1: Introduction
Page 1 - 8 Electrically Operated General Ward Bed
Operation and Maintenance Manual (154588 REV 1)
Knee-Break Operation (Optional)
• To raise the section, press the Knee-break Up control (E) until the
applicable position is reached.
• To lower the section, press the knee-break Down control (F) until the
applicable position is reached.
Backrest and Knee-Break Operation Combined
• To raise the backrest and knee-break together, press the Backrest and
Knee Combined Up control (I) until the applicable position is reached.
• To lower the backrest and knee-break together, press the Backrest and
Knee Combined Down control (J) until the applicable position is reached.
Chair Position Operation
• To go into a seated position, press the Chair Up control (K).
• To go out of a seated position, press the Chair Down control (L).
Attendant Control Panel
The control panel lockout system must be used when patients should
not operate the controls. Failure to operate the bed correctly may cause
injury.
The attendant control panel (ACP) permits one or all of the functions to be
locked out so that the bed can not be operated from the handset.
All models have a self-level feature. If the bed is in an angled position, self-
level will occur at the very low and very high positions. This is to prevent
collisions between the upper mattress frame and the lower wheelbase
assemblies. Also the bed will pause for a moment when level position is
reached.
The typical attendant control panel functions are as follows (see figure 1-4 on
page 1-9):
• Backrest (M)
• Knee-break (N)
•HI/LO (O)
• Trendelenburg (P)
• Bed level (V)
