Chapter 1: Introduction
Page 1 - 10 Electrically Operated General Ward Bed
Operation and Maintenance Manual (154588 REV 1)
Backrest Quick-Release
The quick-release system is to be used for emergency purposes only.
Operation of the quick-release system at the incorrect time can cause
injury or equipment damage.
The backrest actuator is fitted with a quick-release system to let the backrest be
lowered quickly in an emergency.
For normal operation, use the handset or ACP to adjust the backrest position.
To quickly lower the backrest, hold one of the handles (A) at the side of the
backrest and pull up on one of the quick-release levers (B) found at each side
of the bed (see figure 1-5 on page 1-10).
Figure 1-5. Backrest Quick-Release
Knee-Break Feature
When the knee-break is raised or lowered using the controls, the lower leg
section (or foot section) will stay parallel with the bed frame (see figure 1-6 on
page 1-11).
