Features
Chapter 1: Introduction
Electrically Operated General Ward Bed Page 1 - 11
Operation and Maintenance Manual (154588 REV 1)
1
Figure 1-6. Knee-Break Feature
The knee-break foot section may be manually tilted down.
1. To tilt the foot section, hold one of the handles (A) with one hand and pull
up slightly (see figure 1-7 on page 1-11).
2. Lift the support out of the groove and let the foot section lower.
This mechanism will reset itself when the knee-break is lowered to the flat
position.
Figure 1-7. Knee-Break Foot Section Feature
