Specifications
Chapter 1: Introduction
Page 1 - 18 Electrically Operated General Ward Bed
Operation and Maintenance Manual (154588 REV 1)
Recommended mattress dimensions
Mattress width 905 mm
Mattress length 1980 mm
Mattress thickness
e
170 mm (maximum)
Bed height range
f
430 mm to 865 mm (150 mm single
wheel castors)
415 mm to 850 mm (150 mm twin
wheel castors)
470 mm to 905 mm (200 mm single
wheel castors)
a. The minimum bed to wall placement to allow for horizontal arc movement of bed.
b. This dimension is from the floor to the wheelbase frame perimeter.
c. This dimension is from the floor to the wheelbase frame perimeter.
d. This dimension is from the floor to the wheelbase frame perimeter.
e. For a mattress that is other than the recommended thickness, a risk assessment
should be done in relation to the risk that the patient may fall.
f. This measurement is from the floor to the top of the mattress surface.
Feature Dimension
