Sleep Deck
Chapter 5: Parts List
Electrically Operated General Ward Bed Page 5 - 9
Operation and Maintenance Manual (154588 REV 1)
5
Table 5-2. Sleep Deck
The parts in this list are for all models unless otherwise specified.
Item Number Part Number Quantity Description
1 710181 1 ICO foot section panel
2 710182 4 ICO handles
3 710180 1 ICO middle section panel
4 710179 1 ICO fixed section panel
5 710178 1 ICO backrest panel
6 710208 6 Cone lock nut, M8
7 710167 12 Flat washer, M8, 17 mm x 1.2 mm
8 710012 12 Bushing, cast steel hinge, 16 mm x 8 mm
9 710597 9 Bolt, Pozi, M8, 37 mm long, 10 mm
thread
10 710455 1 FE foot section, height adjust
11 710356 1 FE backrest (standard)
711112 1 FE backrest (sliding backrest)
12 710366 1 FE middle section
13 710019 1 FE fixed section (standard)
711120 1 FE fixed section (sliding backrest)
14 710356 1 FE foot section
