Articulating Frame
Chapter 5: Parts List
Electrically Operated General Ward Bed Page 5 - 11
Operation and Maintenance Manual (154588 REV 1)
5
Table 5-3. Articulating Frame
The parts in this list are for all models unless otherwise specified.
Item Number Part Number Quantity Description
1 710509 1 Swing, inner
2 710443 2 Threaded bushing, M8 x 50
3 710524 2 Swing, telescopic axle pin
4 710066 2 Helmut cap, 12 mm
5 710664 1 Swing, telescopic outer, ET
6 713272 1 Main lift, Linak®, Mini-Fit
7 710204 2 FE height lever
8 710300 4 Humpback R. Clip, 2 mm
9 710111 4 Flat washer, 10 mm ID x 21 mm OD x 1.6
mm
10 710520 2 Actuator mount, Pin B, 42.5 mm
Not shown 710466 1 Cable, main lift (Linak, Mini-Fit)
