Lower Frame
Chapter 5: Parts List
Electrically Operated General Ward Bed Page 5 - 13
Operation and Maintenance Manual (154588 REV 1)
5
Table 5-4. Lower Frame
The parts in this list are for all models unless otherwise specified.
Item Number Part Number Quantity Description
1 710203 1 Power box cover
2 710442 4 U-bolt, M10, 46 mm ID
3 710290 4 Screw, self tapping #8 x 1/2" pan head
4 710441 4 Split bushing, plastic
5 710528 1 Gas strut, 900N
6 710066 2 Helmut cap, 12 mm
7 710068 4 Set screw, M8 x 12
8 711967 8 Lock washer, M8 (internal teethed)
9 710412 1 FE wheel base electric tilt
10 710068 4 Set screw, M8 x 12
11 710413 3 Castor, 150 mm single wheel brake
710414 1 Castor, 150 mm single wheel tracking
710987 3 Castor, 150 mm twin wheel brake
710988 1 Castor, 150 mm twin wheel tracking
710985 3 Castor, 200 mm single wheel brake
710986 1 Castor, 200 mm single wheel tracking
12 710197 1 Hex bar, FE wheel base (head end)
13 710202 1 Brake pedal, left
14 710199 1 Brake pedal, right
15 710125 8 Nut, M10, Nylock®
16 710191 1 Hex bar, FE wheel base (head end)
