Upper Frame
Chapter 5: Parts List
Electrically Operated General Ward Bed Page 5 - 15
Operation and Maintenance Manual (154588 REV 1)
5
Table 5-5. Upper Frame
Item Number Part Number Quantity Description
1 713279 1 ACP, Linak®, (electric tilt)
2 710555 4 FE50001 telescopic extension (280 kg)
712370 1 FE50001 telescopic extension (300 kg)
713031 1 FE50002 telescopic extension (250 kg)
712901 1 FE50002 telescopic extension (280 kg)
712900 1 FE50002 telescopic extension (300 kg)
713072 1 FE50003 telescopic extension (250 kg)
713070 1 FE50003 telescopic extension (280 kg)
713071 1 FE50003 telescopic extension (300 kg)
3 710566 1 Telescopic extension lock bar
4 710440 1 FE50001 mattress frame (standard)
710662 1 FE50001 mattress frame (telescopic)
711110 1 FE50001 mattress frame (sliding)
711108 1 FE50001 mattress frame (sliding/tele-
scopic)
712861 1 FE50002 mattress frame (standard)
712862 1 FE50002 mattress frame (telescopic)
712863 1 FE50002 mattress frame (sliding)
712864 1 FE50002 mattress frame (sliding/tele-
scopic)
713059 1 FE50003 mattress frame (standard)
713060 1 FE50003 mattress frame (telescopic)
713061 1 FE50003 mattress frame (sliding)
713062 1 FE50003 mattress frame (sliding/tele-
scopic)
5 710667 2 Mounting kit, control box
6 710469 4 Roofing bolt, phillips head 1/4" x 3/4"
7 713274 1 Actuator, knee-break (Linak®)
8 710077 4 IV socket, head and foot end (FE50001
only)
9 710104 4 Bushing, self-help pole
10 710025 4 Tri-wheel, M8
