Compella™ Bariatric Bed System Instructions for Use (178951 REV 6) 19
• Foot section length adjustment
•Battery backup
• Central braking with heavy duty 6" (15 cm) casters
• Integrated caregiver and patient siderail controls
• One-button cardiac chair position
• Bed exit alert
•Four corner bumpers
• Head angle indicators
• Patient restraint and drainage bag holders
•Night light
INFORMATION INDICATORS
The Information Indicators provide the caregiver with audible indicators and these visual indicators:
Battery Status, Service Required, Bed Not Down, Hip Position Locator, Head Section Angle, and Lift
Position Locator.
There must be either AC or battery power to the bed for the indicators to operate.
AUDIBLE INDICATORS
A single beep will sound when an activity is successful.
A triple beep will sound when there is an error or caregiver attention is needed.
Brake Not Set
The Brake Not Set is an audible alert only. When the bed is plugged into AC power, and you release the
brakes, the alert will sound. To silence the alert, either unplug the bed (for transport) or set the brakes.
Warning—Unless you are to transport a patient, always set the brakes when the bed is occupied. Make
sure the brakes are set before any patient transfer on to or off the bed. Failure to do so may cause
patient or caregiver injury.
VISUAL INDICATORS
Battery Charge Indicator (for Bed Frame Articulations)
This indicator is on the caregiver control panel.
Charged—the Charged (+) indicator comes on when the battery is
charged.
To activate the battery when the bed is unplugged from AC power,
press and hold any articulation control until the articulation starts. There will be a delay of 1-2 seconds
before the articulation control activates the battery.
Low—the Low (-) indicator flashes when the battery is low. An intermittent tone sounds every 2
minutes when the battery reaches a low charge and the bed is unplugged from AC power.
