Specifications
Compella™ Bariatric Bed System Instructions for Use (178951 REV 6) 91
SPECIFICATIONS
Bed Specifications
Feature Dimension
Overall width
a
Maximum (width extenders extended)
Minimum (width extenders retracted)
a. Measured from the outermost points (bumpers), excluding air supply unit and mounting bracket.
53" (135 cm)
43" (109 cm)
Overall length
a
Maximum (foot section extended)
Minimum (foot section retracted)
98" (249 cm)
91" (231 cm)
Sleep deck width 40" to 50" (102 cm to 127 cm)
Sleep deck length 85" to 92" (216 cm to 234 cm)
Minimum Under-bed Clearance 4.25” (10.8 cm)—(hilow in the low position)
6.75” (17.1 cm)—(hilow in the high position)
Hi-Lo
b
Maximum
Minimum
Transport
b. Measured from the top of the seat section outer edge to the floor.
26.8" (68 cm)
18.5" (47 cm)
17" (43 cm)
Patient weight range 113 kg to 454 kg (250 lb to 1000 lb)
Patient height range 50" to 78" (127 cm to 198 cm)
Safe Working Load (including patient,
support surface, and accessories)
500 kg (1100 lb)
Total bed weight (including the Safe
Working Load)
950 kg (2094 lb)
Total bed weight (excluding the Safe
Working Load)
380 kg (838 lb), without the IntelliDrive® XL
Transport System
450 kg (994 lb), with the IntelliDrive® XL
Transport System
Head section angle 0° to 50°
Knee section angle 0° to 30°
Tilt angle 0° to 9°
Reverse Tilt angle 0° to 9°
Caster size 6" (15 cm)
Roller bumper size 4" (10 cm)
