Standard Features
Compella™ Bariatric Bed System Instructions for Use (178951 REV 6) 21
Line-of-Site® Head Angle Indicator
The head angle indicators on the outside of the head siderails mechanically show
the approximate angle of the head section from -8° to +56° with respect to the floor.
The degree where the indicator ball rests is the approximate angle.
No Equipment Zone
WARNING:
Warning—Do not put equipment in the No Equipment Zone area. Equipment damage could occur
when the power drive wheels lower into the Transport position. The damaged equipment could cause
the patient to be injured.
The no equipment zone label identifies the location to avoid
when you put equipment, such as a patient lift device or
overbed table, under the bed.
Refer to this label to make it easier to put the legs of the
equipment under the bed.
STANDARD FEATURES
CPR CONTROLS
NOTE:
CPR is a two-step process if the bed is equipped with an
air surface.
There is a CPR label on the patient right-hand side of the
footboard that shows the locations of the CPR controls for
the air surface and the bed frame.
NOTE:
Earlier versions of the bed may have a different version of
the CPR label.
1. The bed frame CPR control is a red handle that is
under the sleep deck on the patient right-hand side of
the bed at the foot end.
2. The air surface CPR mechanism is on the patient
right-hand side of the surface at the foot end.
The CPR controls for the bed and air surface can be
activated without AC or battery power.
When CPR is activated, any controls that are locked out will become unlocked.
NOTE:
With the foam surface, the use of a CPR board may increase the effectiveness of the CPR.
